胶辊在双向拉伸薄膜领域的应用

胶辊在双向拉伸薄膜领域的应用

Application of Rubber Rollers in Biaxial Stretching Films

1.牵引张力压辊

 Traction Pressure Roller

产品简介

采用高性能耐磨橡胶精制而成，专为薄膜输送和张力调整设计。牵引压辊与牵引辊协同作用，能够保持膜面平整，精准控制张力，实现薄膜的平稳输送，有效提升双向拉伸膜生产线的稳定性和效率，针对横向拉伸后薄膜边部皱褶容易快速磨损压辊边部的问题，我司的专利产品提供了独特解决方案。在辊面工作区域两侧加装薄型耐磨套，耐磨套材料可根据需求选择高性能聚合物或304不锈钢。此设计既保留了橡胶的弹性，又大幅提升了耐磨性能，显著延长了压辊的使用寿命，受到市场的广泛认可。

Product introduction

Made from high-performance wear-resistant rubber, specially designed for film conveying and tension adjustment. The traction pressure roller works in conjunction with the traction roller to keep the film surface flat, precisely control tension, and achieve smooth film conveying, effectively improving the stability and efficiency of the biaxial stretching film production line.A unique solution to edge wear caused by film edge wrinkling after transverse stretching: Our patented product adds thin wear-resistant sleeves on both sides of the roller surface working area. The sleeve material can be selected as high-performance polymer or 304 stainless steel. This design retains the elasticity of rubber while significantly enhancing wear resistance, remarkably prolonging the service life of the pressure roller, and gaining wide market recognition.

2.收卷压辊

Winding Pressure Roller

产品简介

收卷压辊又称接触辊或跟踪辊，专为双向拉伸膜收卷段设计。其核心作用是在收卷过程中将拉伸后的薄膜紧密压实，及时排除膜间空气，防止薄膜松散或起皱。通过有效防皱和增加母卷紧实度，确保薄膜收卷平整、美观，提升收卷质量和生产效率◇成为保障高品质薄膜生产的关键组件。针对超薄薄膜（如电工膜、光学膜等）容易被划伤的问题，我们特别为收卷压辊表面进行了低表面能涂层处理，提供防粘、耐磨、防伤膜的功能，极大提高了薄膜的保护性和耐用性，受到市场的广泛认可。

Product introduction

Winding Pressure Rollers, also known as contact rollers or tracking rollers, are specially designed for the winding section of biaxial stretching film production. Their core function is to tightly compact the stretched film during winding, promptly expel air between film layers, and prevent loose winding or wrinkling. By effectively anti-wrinkling and increasing master roll compactness, they ensure smooth and aesthetically pleasing film winding, enhancing winding quality and production efficiency, and becoming a key component for high-quality film production.

To address the issue of ultra-thin films (such as electrical films and optical films) being easily scratched, our winding pressure rollers feature a low-surface-energy coating on the surface, providing anti-sticking, wear-resistant, and film-protective functions. This significantly improves film protection and durability, gaining wide market recognition.

3.电晕辊与电晕压辊

Corona Rollers and Corona Pressure Rolers

产品简介

电晕辊与电晕压辊，我们生产的电晕辊采用先进的精密数控磨床研磨处理，并通过高压电量检测设备严格测试，确保产品性能稳定后出厂。辊面材料可根据需求选用耐压20-25KV的进口特种硅胶或陶瓷材料，满足不同工艺要求，提供卓越的耐压性能和使用寿命。电晕压辊选用专用 EPDM 等高性能耐磨橡胶精制而成，并可根据需求进行表面涂层处理，实现防粘、耐、防伤膜的功能。尤其在超薄电工膜、光学膜等高要求场景中，展现出显著优势，有效保护膜面质量并提升生产效率我们的电晕辊与电晕压辊设计科学、性能优异，为您的生产线提供高效、持久的保障。

Product introduction

Corona Rollers and Corona Pressure Rollers

Our corona rollers are ground using advanced precision CNC grinders and rigorously tested with high-voltage power detection equipment to ensure stable performance before delivery. The roller surface materials can be selected as imported special silicone rubber (withstand voltage: 20-25KV) or ceramic materials according to process requirements, delivering excellent voltage resistance and service life.Corona pressure rollers are made from high-performance wear-resistant rubber such as special EPDM, and can undergo surface coating treatment to achieve anti-sticking, wear-resistant, and film-protective functions. They exhibit significant advantages in high-demand scenarios such as ultra-thin electrical films and optical films, effectively protecting film surface quality and improving production efficiency.With scientific designs and superior performance, our corona rollers and corona pressure rollers provide efficient and durable support for your production line.
